JBL Bar 5.1 Surround

JBL

Model #:

Bar 5.1 Surround

Model #: Bar 5.1 Surround
534995
JBL
$499.95

At a Glance

5.1 channel soundbar with MultiBeam™ Sound TechnologyRead More

$499.95

Get to know this product.

Product Overview

Product Overview

General SpecificationsModelBar 5.1 CNTR (Soundbar Unit), BAR 5.1 SUB (Subwoofer Unit)Power supply100 - 240V AC, ~ 50/60HzSoundbar output power (Max. @THD 1%)5 x 50WSubwoofer output power (Max. @THD 1%)300Wstandby power<0.5Wnetworked standby power<2.0WOperating temperature0°C - 45°CBAR 5.1 SURROUND is in compliance with European Commission Regulation (EC) No 1275/2008 and (EU) No 801/2013.YesOff ModeN/ANetwork Standby<2.0WTime to standby<20minutes* Standbyin the condition of all wireless connections of Soundbar are deactivated, if no provide any audio or video signal to the Soundbar unit, the Soundbar unit will automatically into standby mode in 10 minutes.* Networked standbyin the condition of any wireless connection of Soundbar is activated, if no provide any audio or video signal to the Soundbar unit, the Subwoofer and Soundbar unit will automatically into networked standby mode in 10 minutes.Any audio or video recover will bring device from standby to operation mode.YesAudio SpecificationsTotal speaker power output (Max. @THD 1%)550W



Max SPL103dB

Frequency response40Hz - 20KHzAudio inputs1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)MP3 CodecMPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3MP3 sampling rate16KHz - 48 KHzMP3 bitrate80kbps - 320kbpsWAV sample rate16KHz - 48 KHzWAV bitrateUp to 3000kbpsDimensionsSoundbar transducer5 x 4690” racetrack drivers +2 x 1.25” side-firing tweetersSubwoofer transducer10”Dimensions (W x H x D)1018 x 58 x 100mm / 40” x 2.28” x 3.94” (Soundbar); 305 x 440 x 305mm / 12” x 17.3” x 12” (Subwoofer)Weight2.85KG (Soundbar); 10.62Kg (Subwoofer)Control and Connection SpecificationsUSB portType AUSB rating5V DC, 0.5ASupporting file formatmp3, wavBluetooth version4.2Bluetooth profileA2DP V1.3, AVRCP V1.5Bluetooth frequency range2402MHz - 2480MHzBluetooth Max. transmitting power<11dBm (EIRP)Modulation TypeGFSK, π/4 DQPSK, 8DPSKWi-Fi networkIEEE 802.11 a/b/g/n/ac (2.4GHz/5GHz)2.4G Wi-Fi frequency range2412 – 2472MHz (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)2.4G Wi-Fi Max. transmitting power<20dBmModulation TypeDBPSK, DQPSK, CCK, QPSK, BPSK, 16QAM, 64QAM5G Wi-Fi frequency range5.15 - 5.35GHz, 5.725 - 5.825GHz5G Wi-Fi Max. transmitting power<22dBmModulation TypeQPSK, BPSK, 16QAM, 64QAM, 256QAM5G Wireless frequency range5161.35 - 5245.35MHz, 5736.35 - 5820.35MHz5G Max. transmitting power<9dBm (EIRP)Modulation Typeπ/4 DQPSKVideo SpecificationsHDMI Video input1

HDMI Video output (With Audio return channel)

1

HDMI HDCP version2.2
